პროდუქტის კოდი: 9568
ბრენდი: ZKTeco
inPulse+
მახასიათებლები:
(ყველას ნახვა)
Access Control Interface
Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor / Doorbell Output
Card Capacity
2,000
Communication
TCP/IP / USB Host / Wiegand Input / Output / Security Relay Box
Current Draw
< 500mA
Dimension
201.7 × 85 × 102.7 mm
Finger Vein & Fingerprint
FAR≤0.0001%, FRR≤0.01%
აღწერილობა
inPulse+ is a multi-biometric reader capable of capturing and processing finger vein and fingerprint biometric data at the same time. Ergonomic, intuitive and highly secured, inPulse+ leads us to a new era of enhancing security with biometrics. Its infra-red rays illuminate the vein pattern which is then converted into a biometric template. Both the vein and fingerprint templates are then stored in the database for subsequent matching.
მახასიათებლები
General
Access Control Interface
Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensor / Doorbell Output
Card Capacity
2,000
Communication
TCP/IP / USB Host / Wiegand Input / Output / Security Relay Box
Current Draw
< 500mA
Dimension
201.7 × 85 × 102.7 mm
Finger Vein & Fingerprint
FAR≤0.0001%, FRR≤0.01%
Finger Vein Capacity
1,500
Fingerprint Capacity
1,500
Hardware
1.2GHz High Speed CPU / Memory 128MB RAM / 256MB Flash / ZK Fingerprint Sensor / 2.8 Inches TFT-LCD Touch Screen / 125KHz EM Reader / Mifare (Optional) / Hi-Fi Voice & Indicator / Tamper Switch Alarm
Operating Voltage
12V DC
Special Function
Multiple Biometric Verification Modes / ZK Encrypted Card (Optional)
Standard Function
Access Levels / Groups / Holidays / DST / Bell Schedule / Duress Mode (Password) / Anti-Passback / Record Query / Custom Wallpaper & Screen Saver
Transaction Capacity
100,000
ALGORITHM
ZKVein V3.0 & ZKFinger V10.0
COMPATIBILITY
Wiegand Slave Reader / ZKBioSecurity Software
Operating temperature
-10°C ~ 50°C
