SpeedFace-V3LM1

Name: SpeedFace-V3LM1
Brand: ZKTeco
Availability: InStock

All about product

Specification

New

Pre-Order

Product Code: 9496

Brand: ZKTeco

SpeedFace-V3LM1

Specifications: (See all)

Authentication Method

Fingerprint / Face / Card / Password (Virtual Keypad)

Biometric Algorithm

ZKFace 3.5ZKFingerprint V10.0

Biometric Verification Speed

less than 1 sec (Facial Recognition)

Camera

Binocular Camera @ 1MP

Card Capacity

3,000 (1:N) (Optional: 10,000)3,000 (1:1) (Optional: 10,000)

Card Type

ID Card@125 kHz (Optional) IC Card@13.56 MHz (Optional)

Description

SpeedFace-V3LM1 is an efficient Linux-based access control terminal, utilizing visible light technology for a comprehensive security management. This terminal provides dual authentication methods, including facial recognition and fingerprint verification.

Also, SpeedFace-V3LM1 is equipped with an ultimate anti-spoofing algorithm for facial recognition against all types of fake photos and videos attack. Additionally, there are different versions of SpeedFace-V3LM1 to satisfy your needs.

SpeedFace-V3LM1 [QR] comes with a QR code module, while the SpeedFace-V3LM1 [RFID] supports RFID cards verification function. The USB facial recognition extension reader KF1000-U is compatible with SpeedFace-V3LM1, offering a two-way verification and facial recognition access control management. SpeedFace-V3LM1 series is also compatible with ZKBio CVAccess and ZKBio Zlink Mobile APP & ZKBio Zlink-Web when switching to BEST protocol.

Specifications

General

Authentication Method

Fingerprint / Face / Card / Password (Virtual Keypad)

Biometric Algorithm

ZKFace 3.5ZKFingerprint V10.0

Biometric Verification Speed

less than 1 sec (Facial Recognition)

Camera

Binocular Camera @ 1MP

Card Capacity

3,000 (1:N) (Optional: 10,000)3,000 (1:1) (Optional: 10,000)

Card Type

ID Card@125 kHz (Optional) IC Card@13.56 MHz (Optional)

Certifications

ISO14001, ISO9001, CE, FCC

Communication

TCP/IP *1, Wi-Fi(Optional), Wiegand Input *1, Wiegand Output *1, RS485: ZKTeco RS485*1, Auxiliary Input, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1, Doorbell*1

Face Template Capacity

500 (1:N) (Optional: 1,500)500 (1:1) (Optional: 1,500)

False Acceptance Rate (FAR) %

FAR ≤ 0.01% (Visible Light Facial Recognition) FAR ≤ 0.0001% (Fingerprint; ZKFingerprint V10.0)

False Rejection Rate (FRR) %

FRR ≤ 0.02% ( Visible Light Facial Recognition)FRR ≤ 0.01% ( Fingerprint: ZKFingerprint V10.0)

Fingerprint Template Capacity

3,000 (1:N) (Optional: 5,000)3,000 (1:1) (Optional: 5,000)

Gross Weight

0.8 kg

Hardware

1.2GHz Dual Core CPU256MB RAM / 512MB ROM 1MP Binocular Camera ; Adjustable LED Supplement Light

Ingress Protection Rating

IP65

Installation

Wall-mount (Compatible with Single Gang-Box)

Net Weight

0.3 kg

Operating Humidity

10% to 90% RH (Non-condensing)

Operation System

Linux

Standard Functions

ADMS, DST, 14-digit User ID, Access Levels, Groups, Holidays, Anti passback, Record Query, Tamper Switch Alarm, Multiple Verification Methods

Supported Software

Software: ZKBio CVAccessMobile App: ZKBio Zlink / ZSmartCloud Service: ZKBio Zlink

Touchless Biometric Recognition Distance

0.5 m to 2 m (Facial Recognition)

Transaction Capacity

200,000

MODEL

SpeedFace-V3LM1

Display

2.4-inch touch Screen (240*320)

QR CODE

QR code, Bar code, PDF417(Optional), Data matrix(Optional), MicroPDF417(Optional), Aztec(Optional)

POWER SUPPLY

12V 3A

Operating temperature

-5°C to 45°C

Dimensions

188 x 60 x 21 mm (L*W*H)
