SpeedPalm-V5L

Name: SpeedPalm-V5L
Brand: ZKTeco
Availability: OutOfStock

All about product

Specification

New

Pre-Order

Product Code: 9489

Brand: ZKTeco

SpeedPalm-V5L

Specifications: (See all)

Authentication Method

Face / Palm / Card / Password (Virtual Keypad)

Biometric Algorithm

ZKFace V3.9 & PalmElite3.3.3

Biometric Verification Speed

less than 1 sec (Facial Authentication)less than 0.35 sec (Palm Authentication)

Camera

WDR Low Light Camera @ 2MP

Card Capacity

20,000 (1:N)

Card Type

ID Card@125 kHz (Standard) IC Card@13.56 MHz (Optional)

Description

SpeedPalm-V5L is a smart access control terminal equipped with the visible light face and palm authentication technology, which applies the latest algorithms and advanced computer vision technology. It supports a variety of identification methods, including face/palm/card, etc. Besides, the terminal supports large capacity and speedy authentication.

SpeedPalm-V5L eliminates hygiene concerns with contactless biometircs technology. It is also equipped with anti-spoofing algorithms for facial and palm authentication to defend against almost all types of fake photo and video attacks. Importantly, high-precision palm authentication takes only 0.35s per hand. The palm data is then compared to the maximum of 5,000 palm templates.

Besides, SpeedPalm-V5L is an access control terminal featuring a video intercom function. It fully improves the video intercom experience and can be compatible with video intercom indoor unit with SIP protocol.

Specifications

General

Authentication Method

Face / Palm / Card / Password (Virtual Keypad)

Biometric Algorithm

ZKFace V3.9 & PalmElite3.3.3

Biometric Verification Speed

less than 1 sec (Facial Authentication)less than 0.35 sec (Palm Authentication)

Camera

WDR Low Light Camera @ 2MP

Card Capacity

20,000 (1:N)

Card Type

ID Card@125 kHz (Standard) IC Card@13.56 MHz (Optional)

Certifications

ISO14001, ISO9001, CE, FCC, RoHS

Communication

TCP/IP*1 Wi-Fi (IEEE 802.1 a/b/g/n/ac) @2.4GHz ; 5GHzWiegand (Input or Output)*1 RS485: ZKTeco RS485*1 Aux Inputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm *1

Face Template Capacity

10,000 (1:N)

False Acceptance Rate (FAR) %

FAR ≤ 0.01% (Visible Light Facial Authentication)FAR ≤ 0.01% (Palm Authentication)

False Rejection Rate (FRR) %

FRR ≤ 0.02% ( Visible Light Facial Authentication) FRR ≤ 0.17% (Palm Authentication)

Gross Weight

1.3 Kg

Hardware

CPU: 1GHz Dual CoreRAM: 1G; ROM: 8GSupplement Light: Yes

Housing Material

Aluminium Alloy

Ingress Protection Rating

Installation

Wall-mount (Compatible with Asian Gang-box / Single Gang-Box)

Net Weight

0.62 Kg

Operating Humidity

10% to 90% RH (Non-condensing)

Operation System

Linux

Optional Functions

IC Card, ZSmart APP

Palm Template Capacity

15,000 (1:N)

Standard Functions

ADMS, T9 Input, 14-digit User ID, Access Levels, Groups, Holidays, Antipassback, Record Query, Schedule Bell, Tamper Switch Alarm, Mask Detection ,Multiple Verification Methods, SIP 2.0 Protocol, AC Push and TA Push Protocol Switch

Supported Software

Software: ZKBio CVAccess / ZKBio Time / ZKBio CVSecurityMobile App: ZSmart

Touchless Biometric Recognition Distance

1cm to 100cm (Facial Authentication) 5cm to 15cm (Palm Authentication)

Transaction Capacity

200,000

Visual Indicator

Steady Green LED: Normal StatusSteady White LED: Authentication in ProgressSteady Red LED: Error/ FaultSteady Orange LED: Object nearby detected

MODEL

SpeedPalm-V5L

Display

5"@ ISP Color LCD Touch Screen (720*1280)

POWER SUPPLY

12V DC 3A

Operating temperature

-10°C to 45°C (14°F to 113°F)

Dimensions

227.3 *92.3 * 24.5 (mm) (L*W*D)
